MSHOT MD50 digital microscope camera with Standard C-MOUNT can be connected to various kinds of microscopes. Successful high-sensitivity and rapid data transfer enable MD50 digital microscope camera be popular with customers from industrial, medical, traffic and mechanical Vision fields etc. MD50 will make your work more convenient and more efficient than before.
Key parameters:
◆5.0 megapixels, progressive scanning CMOS sensor.
◆No compression, no interpolation.
◆Support still image capture(JPG,BMP)
◆USB2.0 interface, up to 480MPS, external power no need.
◆Standard C-MOUNT, durable aluminum alloy casing.
Feature:
◆5 megapixels MSHOT MD50 uses a 2592x1944 pixel color CMOS
◆Interfaced to a computer via USB2.0 technology for rapid image download.
◆It uses a 12-bit analog to digital converter, recording subtle color differences important for accurate color reproduction. The result is images with outstanding color and fine detail.
◆Plug-to-play, no need extra power
◆Easy store and recall feature allows the user to retrieve the same settings for further analysis or comparison.
Specification:
| Item |
Specification |
Item |
Specification |
| Sensor |
1/2.5″CMOS |
Sensitivity |
0.53 V/lux-sec (550nm) |
| Resolution |
2592x1944(12bit) |
Data Interface |
USB2.0 (480 Mbit / sec) |
| Pixels |
2.2μm x 2.2μm |
Power Supply |
DC 5V ± 5% |
| Frame Rate |
12fps@2592x1944 |
Electricity |
≈200 mA |
| 30 fps@640x480 |
White Balance |
Manual/Auto one-touch |
| Shutter |
Electronic |
Exposure Control |
10μs–32ms Auto exposure |
| S/N Ratio |
40.5dB |
Software |
Display/Film/Video |
| Scan mode |
Progressive scanning |
Operating Temp. |
-30°C ~ 70°C |
